Read MoreAll dimensions in the below table are in mm. |
|||||
| FROM | Up To/Not Including | ≥600-1200 | ≥1200-1500 | ≥1500-1800 | ≥1800-2000 |
| 1.5 | 2 | ±0.11 | ±0.12 | ±0.14 | - |
| 2 | 2.5 | ±0.12 | ±0.14 | ±0.15 | ±0.16 |
| 2.5 | 3 | ±0.13 | ±0.14 | ±0.16 | ±0.17 |
| 3 | 4 | ±0.14 | ±0.16 | ±0.17 | ±0.18 |
| 4 | 5 | ±0.16 | ±0.17 | ±0.18 | ±0.19 |
| 5 | 6 | ±0.17 | ±0.18 | ±0.19 | ±0.20 |
| 6 | 8 | ±0.19 | ±0.20 | ±0.20 | ±0.23 |
| 8 | 10 | ±0.21 | ±0.22 | ±0.22 | ±0.26 |
| 10 | 12.5 | ±0.23 | ±0.24 | ±0.24 | ±0.28 |
| 12.5 | 15 | ±0.24 | ±0.25 | ±0.26 | ±0.30 |
| 15 | 20 | ±0.26 | ±0.28 | ±0.30 | ±0.33 |
The thickness tolerances depend on specification like, ASTM, IS, EN, DIN etc. However, the above table represents the typical thickness tolerances offered.
